Network Switches GWN7806P

Category: Network Switches

Price: Contact

(*) Giá chưa bao gồm thuế VAT

48 Gigabit Ethernet ports and 6 Gigabit SFP+ ports

Smart power control to support dynamic PoE/PoE+ power allocation per port for the PoE models

Supports deployment in IPv6 and IPv4 networks

ARP Inspection, IP Source Guard, DoS protection, port security & DHCP snooping

Enterprise-Grade Layer 2+ Managed Network Switch
The GWN7806(P) is a high-performance layer 2+ managed network switch with 48 ports that allows small-to-medium enterprises to build scalable, secure, and smart business networks that are fully manageable

48 Gigabit Ethernet ports and 6 Gigabit SFP+ ports
Smart power control to support dynamic PoE/PoE+ power allocation per port for the PoE models
Supports deployment in IPv6 and IPv4 networks
Reliability features including fault detection, device protection, dual boot, dual system file redundancy, link aggregation, storm control, and more
ARP Inspection, IP Source Guard, DoS protection, port security & DHCP snooping
Embedded controller to manage switch; GWN.Cloud and GWN Manager, Grandstream’s cloud and on-premise Wi-Fi management platform
Built-in QoS allows for prioritization of network traffic
Supports stacking for easy management of up to 16 switches in one interface while creating redundant backup between multiple devices

Specifications

Model	GWN7806P
Network Protocol	• IPv4, IPv6, IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3af/at, IEEE 802.1p, IEEE 802.1Q, IEEE 802.3AB, IEEE 802.1p, IEEE 802.1D, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x
Gigabit Ports	• 48
SFP+ Ports	• 6
Console	• 1
# of PoE Ports	• 48
Integrated Power Supply	• 470W
Maximum Output Power Per PoE Port	• 30W
Max Total PoE Output Power	• 400W
PoE Standards	• IEEE 802.3af/at
Auxiliary Ports	• 1x Reset Pinhole
Forwarding Mode	• Store-and-forward
Total non-blocking throughput	• 108Gbps
Switching Capability	• 216Gbps
Forwarding Rate	• 160.704Mpps
Packet Buffer	• 16Mb
Switching	• 32K static, dynamic and filtering MAC addresses • 4K VLANs, port-based VLAN, IEEE 802.1Q VLAN tagging, voice VLAN • VLAN virtual interface • GVRP (pending) • 27 link aggregation • Spanning tree, 64 instances for STP/RSTP/MSTP
Routing	• Static routing
Multicast	• IGMP Snooping • MLD Snooping • MVR (pending)
QoS/ACL	• Port priority • Priority mapping • Queue scheduling, including SP, WRR, WFQ, SP-WRR and SP-WFQ • Traffic shaping • Rate limit • 4K ACL for Ethernet, IPv4 and IPv6
DHCP	• DHCP server, DHCP relay, DHCP Option 82, 60, 160 and 43
Maintenance	• CPU and memory monitoring, SNMP, RMON, LLDP&LLDP-MED, backup and restore, syslog, diagnostics including Ping, Traceroute, port mirroring, UDLD(TBD) and copper test
Security	• User hierarchical management and password protection, HTTPS, SSH, Telnet • 802.1X authentication • AAA authentication including RADIUS, TACACS+ • Storm control • Port isolation, port security, sticky MAC • Filtering MAC address • IP source guard, DoS attack prevention, ARP inspection • DHCP Snooping • Loop protection including BPDU protection, root protection (pending) and loopback protection (pending) • Kensington Security Slot (Kensington Lock) support
Mounting	• Desktop, Rack-Mount(rack-mounting kits included)
LEDs	• 1x tri-color LED for device tracking and status indication • 54x green-color LEDs for data transferring • 48x yellow-color LEDs for PoE powered
Fan	• 3
Environmental	• Operation: 0°C to 45°C, humidity: 10% to 90% RH(Non-condensing) • Storage: -10°C to 60°C, humidity: 10% to 90% RH(Non-condensing)
Dimensions	• 440mm(L) x 301mm(W) x 44mm(H)
Unit Weight	5.1Kg
Package Content	• Switch, 1x 1.2m(10A) AC Cable, 1x 25cm Ground Cable, 4x Rubber Footpads, 2x Rack-Mounting Kits, 8x Screws(PM 3*6), 1x Power Cord Anti-Trip, 1x Quick Installation Guide, 1x Console Cable(Optional)
Compliance	• FCC, CE, RCM, IC, UKCA
